Transition union male

Description

A fitting used for the transition from a welded part of a water or heating distribution system to brass dismountable joints.

Selection of colors: Výběr barev

See explanation of symbols

Features List

D, D1 D2, G A B, R B1 C
20 × 1/2" pcs 125 1 0,11 0,09 237020 20 1/2" 14,50 41,00 53,00
25 × 3/4" pcs 65 1 0,19 0,17 237025 25 3/4" 16,00 44,00 59,00
32 × 1" pcs 50 1 0,25 0,22 237032 32 1" 18,10 46,00 63,00
40 × 5/4" pcs 25 1 0,36 0,44 237040 40 5/4" 20,50 51,00 68,00
50 × 6/4" pcs 20 1 0,59 0,55 237050 50 6/4" 23,50 52,00 70,00
63 × 2" pcs 8 1 1,03 1,37 237063 63 2" 27,40 64,00 90,00

Screwed joints at combined fi ttings with a metal thread need to be sealed only with a Tefl on band or special sealing putty containing Tefl on. It is suffi cient to apply it on the fi rst two or three threads. Never use classical hemp – after it absorbs water, the thread may crack due to the inner pressure.
